Greenhouse Light Diffusion Screen- LDS Series

Our SCREENMAX LDS Series of greenhouse screens is engineered for precise sunlight management.

Available in both open and closed structures, these screens facilitate uniform light distribution, control over solar radiation, and temperature regulation, all while promoting better ventilation (Open structure) or energy saving and heat preservation (Closed structure).

  • Energy Saving Rate: 15% to 47%
  • Light Transmission Rate: 14% to 54%
  • Shading Rate Range: 46% to 85%
  • MOQ: 2000m²

Our products tested by:

AWTA product testing
R&D Services


Basic Info of SCREENMAX Light Diffusion Shading Screen – LDS Series

Features Details
Series LDS
Application Greenhouse Use
Design Structure Available in Open and Closed configurations
Strip Width 4MM
Shrinkage ≤ 1% after treatment at 80°C for 2 hours
Energy Saving Rate Range: 15% to 47%
Light Transmission in Sunlight Range: 14% to 54%
Shading Rate Range: 46% to 85%
Delivery Time 10-20 days
Minimum Order Quantity 2000m²

For collaboration inquiries, please contact us for more details. (We accept OEM and ODM).

About SCREENMAX LDS Series Greenhouse Screens

The SCREENMAX LDS Series of greenhouse screens are meticulously designed to manage sunlight exposure within the greenhouse environment. These screens are available in both Open and Closed structure configurations to cater to different greenhouse needs. The closed structure ensures a uniform distribution of light, limiting direct sunlight that could potentially harm crops while also aiding in energy saving and heat preservation at night. On the other hand, the open-hole structure promotes better ventilation, ensuring a conducive climate for plant growth.

Benefits of the LDS Series include:

  • Uniform light distribution
  • Control over solar radiation and crop temperature
  • Enhanced ventilation (Open structure)
  • Energy saving and heat preservation (Closed structure)

LDS Series Specifications

Type Energy Saving Rate Light Transmission in Sunlight Shading Rate Width of Strips (mm) Shrinkage Weight per sqm (g/m²)
LDS45-close 47% 54% 46% 4 80°C 2hrs ≤ 1% 65±5
LDS50-close 15% 48% 52% 4 80°C 2hrs ≤ 1% 70±5
LDS60-close 45% 39% 60% 4 80°C 2hrs ≤ 1% 85±5
LDS70-close 45% 14% 70% 4 80°C 2hrs ≤ 1% 90±5
LDS60-open 20% 40% 60% 4 80°C 2hrs ≤ 1% 60±5
LDS85-open 45% 15% 85% 4 80°C 2hrs ≤ 1% 85±5
